The Q16FX is a 16-channel analogue mixing console designed and engineered in the UK. The Q16FX consists of 16 input channels: 10 mono channels with microphone inputs utilising low-noise microphone preamps plus a line-in option on each channel alongside 4 stereo line input channels perfect for electric pianos, synthesizers, drum machines, audio from external media players or any other line level sources.
Channels 1 to 8 feature an easy-to-use single-knob compressor giving you full control over the dynamic range of your input sources. A low cut at 75Hz plus a 3-band EQ is available on each channel allowing you to shape the tone of individual sound sources helping you to create a beautifully balanced mix.
16-high-quality DSP effects offer even more options for your audio productions with multiple reverbs, delays and echoes to choose from. The 9-band graphic EQ with feedback detection allows you to grasp the sound of your mix as a whole and adjust accordingly before sending it to front of house.
The Q16FX also offers 2 Subgroups to give you further control, allowing you to adjust the level of the channels routed to each group with ease. 2in/2out USB functionality makes the Q16FX the perfect tool for recording performances, podcasts, and music production.
All of this combined with comprehensive monitoring, 2 auxiliary sends, RCA in and out, global phantom power, pan on each channel, and a 12-point LED meter for your main mix all housed in a robust chassis make the Q16FX a complete portable powerhouse for traveling musicians and engineers alike.
FEATURES
- 16 Channels
- 10 Mic inputs
- USB audio in/out
- Global phantom power
SPECIFICATIONS
- Mic Inputs: 10 x XLR CH1-12
- Line Inputs with Mic (Stereo): 2 x Stereo ¼” 6.3mm TRS CH9-12
- EQ: 3 band (±15dB), Low 100Hz, Mid 2.5kHz, High 12kHz per channel
- Compressor: 2:1 ratio 9dB makeup gain, -8dBu input threshold (max compression, Ch1-8)
- Monitors: Stereo ¼” 6.3mm TRS Sockets
- FX Send: Mono ¼” 6.3mm TRS
- Phones: Mono ¼” 6.3mm TRS
- Effects: 16 Reverb and delay effects with enable switch and parameter control.
- USB Audio: Inputs/Outputs: 2-in/2-out, 24-bit, Sample Rate 48kHz
- Line Inputs (Mono): 48 x ¼” 6.3mm TRS CH1-8
- Line Inputs (Stereo): 2 x Stereo ¼” 6.3mm TRS CH13-16
- Low Cut: 75Hz cut off @ 18dB/Octave (CH1-12)
- Main Outputs: Balanced Stereo XLR
- Sub Outputs: 2 x ¼” 6.3mm TRS Sockets
- Aux Send: Mono ¼” 6.3mm TRS
- RCA: Stereo Phono Sockets
- Graphic EQ: Master 9 Band Graphic EQ with feedback detect, on/off toggle
- AC Power: Universal 100-240V ~ 50/60Hz (EIC C14 Socket, AC Cord included)
- Dimensions (HWD): 107 x 509.5 x 443mm (4.2" x 20.1" x 17.4")
- Weight: 7.5 Kg (16.5 lbs)
